Piling Driving, Auger Driver, Continuous Flight Augering, Tysim Kr90m Cfa Long Spiral Rotary Drilling Rig Max Piling Depth 30m

TYSIM Piling Equipment Co., Ltd.
  • Certification：CE, ISO 9001:2000
  • Condition：New
  • Drill Hole Diameter：600mm
  • Drill Hole Depth：12m
  • Bit Type：Cfa Auger
  • Drilling Way：Rotary

Base Info

  • Model NO.：KR90M
  • Type：Crawler
  • Torque：90 Kn.M
  • Max. Diameter：600 mm
  • Max. Drilling Depth：12 M
  • Ocerall Weight：28t
  • Main Pull：90 Kn.M
  • Transport Package：Bulk Pack
  • Specification：28 t
  • Trademark：TYSIM
  • Origin：Jiangsu, China
  • HS Code：8431499900
  • Production Capacity：30 Sets,Month

Description

CFA construction method Max. diameter600mmMax. drilling depth12mMain winch line pull90 kNRotary drilling construction methodMax. Diameter1000/1200 mmMax. drilling depth32 mMain winch line pull 90 kNMain winch line speed75 m/minWorking parametersMax. torque90 kN.mAuxiliary winch line pull35 kNAuxiliary winch line speed40 m/minMast inclination(lateral)±3°Mast inclination(forward)4°Max. operating pressure35 MPaPilot pressure3.9 MPaTravel speed2.8 km/hTraction force 156 kNOperating sizeOperating height16000mm(CFA)/14550mm(rotary drilling)Operating width2600 mmTransport sizeTransport height3480 mmTransport width2600 mmTransport length13100 mmTotal weightOverall weight28 t

Product Details

1. Undercarriage-----Reliable & Mature Excavator Supplier for Choice

Type: New & Used

Brand: CAT, JCM, SINOMACH, SANY, and other

2. Hydraulic Parts-----Famous Brands

Gearbox Reducer: Imported REXROTH

Main Pump & Valve: Imported KAWASAKI (Japan)

Hose: Imported

3. Structure Parts-----Professional Structure Parts Supplier

Piling Driving, Auger Driver, Continuous Flight Augering, Tysim Kr90m Cfa Long Spiral Rotary Drilling Rig Max Piling Depth 30mPiling Driving, Auger Driver, Continuous Flight Augering, Tysim Kr90m Cfa Long Spiral Rotary Drilling Rig Max Piling Depth 30m


Piling Driving, Auger Driver, Continuous Flight Augering, Tysim Kr90m Cfa Long Spiral Rotary Drilling Rig Max Piling Depth 30mPiling Driving, Auger Driver, Continuous Flight Augering, Tysim Kr90m Cfa Long Spiral Rotary Drilling Rig Max Piling Depth 30m




Why Choose Us?

1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.

2. Supply professional customized service to meet all your requirements.

3. Our rotary drilling rigs have been sold to more than 7 counstries, such as Russia, Australia, Thailand, Zambia and others.

4. Competitive price.


FAQ

Q1: What is the Warranty of the Rotary Drilling Rig?

The warranty period for new machine is one year or 2000 working hours, whichever comes first will be applied.

Please contact with us for detailed Warranty Regulation.

Q2: What's your service ?

We can offer professional technical support and good after-sale service to you.

Modification methods will be different according to different models and configurations of your owned excavators.

Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.

Before modifying, you need to confirm technical specification.
